3D Printer Filtration V1 Filters, HEPA H13 & Activated Carbon Air Purifier for 3D Printer Enclosure, ABS/ASA VOC Odor Remover and Ultrafine Particle Trap, 3-Stage Filtration for V1 System in Kuwait

System V1

KWD 14
Brand
Mintion
Weight
264 g
ColorSystem V1
– 1 +

Special Features

  • 🔹 Three-Stage Filtration System – Complete Air Protection： This replacement filter kit features a three-stage filtration system purpose-built for 3D printing. The Pre-Filter captures stringing debris and coarse dust, the HEPA H13 Rated Filter traps ≥99.95% of ultrafine particles (UFPs < 100 nm), and the High-Iodine Activated Carbon removes VOCs and odors like styrene (ABS/ASA), caprolactam (Nylon/PA), and acetaldehyde (PLA/PETG).
  • 🔹 HEPA H13 Grade Filtration for Hazardous Particles: 3D printing generates invisible hazardous ultrafine particles that can linger in the air. The HEPA H13 rated filter delivers ≥99.95% filtration efficiency at MPPS, capturing particles smaller than 100 nanometers to keep the air inside your 3D printer enclosure clean and safe.
  • 🔹 Dual Carbon Layer Option for Heavy VOC Printing (ABS/ASA): For users printing primarily with ABS or ASA filaments, the filter housing allows an alternative stacking configuration using two activated carbon stages (replacing the pre-filter) to significantly increase styrene and VOC adsorption capacity. Includes detailed instructions for optimal setup.
  • 🔹 3-Month Typical Lifespan with Easy Replacement Cadence: For standard printing (PLA/PETG and mixed filaments, ~8 hours/day), each filter set typically lasts about 3 months. Replace sooner if you notice reduced airflow, odor breakthrough, or visible filter discoloration—keeping your Mintion V1 filtration system performing at its best.
  • 🔹 Designed Exclusively for Mintion 3D Printer Filtration System V1: This filter kit is specifically engineered for the Mintion V1 Filtration System. It is not compatible with earlier designs or other brands, ensuring a perfect fit and optimal sealing for maximum filtration efficiency. Simply trim the foam gasket when using HEPA as the first stage—no cutting into filter media required.

Description

Three-Stage Filter Core — Purpose-Built for 3D Printing
Pre-Filter: Captures stringing debris, and coarse dust to protect the downstream media and extend service life.
HEPA H13: Rated ≥99.95% at MPPS, highly effective against ultrafine particles (UFPs
Activated Carbon: High-iodine pellet carbon for VOC and odor removal—targets styrene (ABS/ASA), caprolactam (Nylon/PA), and acetaldehyde/lactide (PLA/PETG).

Recommended Stacking & Replacement
General use (PLA/PETG and mixed filaments)
Stacking order: Pre-Filter → HEPA H13 → Activated Carbon
Typical replacement cadence: printing ~8 hours/day → ~3 months per set (actual life varies with material, enclosure cleanliness, and fan speed). Replace sooner if you notice airflow drop, odor breakthrough, or visible discoloration.
VOC-heavy use (ABS/ASA focus)
Alternative stacking for stronger odor control: HEPA H13 → Activated Carbon → Activated Carbon
(Replace the pre-filter with a second carbon stage for increased styrene adsorption. If your enclosure is dusty, keep the pre-filter and shorten the carbon change interval.)
Note: Due to the housing design, the pre-filter uses a half-width outer foam. When using HEPA H13 as the first stage, trim off half of the outer foam gasket on the HEPA's intake/outside-facing edge to ensure proper fit and airflow sealing. Trim foam only—do not cut into the filter media.

Compatibility
This filter core is designed exclusively for the Mintion 3D Printer Filtration System V1.
