Air Bearings
Model: S6900 RS
Structure: Deep Groove Ball
Material: Hybrid Ceramic
Bore Dia (d): 10 mm
Outer Dia (D): 22 mm
Width (B): 6 mm
Closures: Sealed (2RS)
Lubrication: Grease
Clearance: C0
Dynamic Load Rating (Cr) (Newtons): 610
Static Load Rating (Cor) (Newtons): 290
Weight: 0.001 kg
Quantity: 1 Lot = 1 PC
Model: S6801 RS
Structure: Deep Groove Ball
Material: Hybrid Ceramic
Bore Dia (d): 12 mm
Outer Dia (D): 21 mm
Width (B): 5 mm
Closures: Sealed (2RS)
Lubrication: Grease
Clearance: C0
Dynamic Load Rating (Cr) (Newtons): 430
Static Load Rating (Cor) (Newtons): 220
Weight: 0.006 kg
Quantity: 1 Lot = 1 PC
Model: S6000 RS
Structure: Deep Groove Ball
Material: Hybrid Ceramic
Bore Dia (d): 10 mm
Outer Dia (D): 26 mm
Width (B): 8 mm
Closures: Sealed (2RS)
Lubrication: Grease
Clearance: C0
Dynamic Load Rating (Cr) (Newtons): 1030
Static Load Rating (Cor) (Newtons): 440
Weight: 0.019 kg
Quantity: 1 Lot = 1 PC
Model: S6901 RS
Structure: Deep Groove Ball
Material: Hybrid Ceramic
Bore Dia (d): 12 mm
Outer Dia (D): 24 mm
Width (B): 6 mm
Closures: Sealed (2RS)
Lubrication: Grease
Clearance: C0
Dynamic Load Rating (Cr) (Newtons): 650
Static Load Rating (Cor) (Newtons): 330
Weight: 0.011 kg
Quantity: 1 Lot = 1 PC
Model: S6800 RS
Structure: Deep Groove Ball
Material: Hybrid Ceramic
Bore Dia (d): 10 mm
Outer Dia (D): 19 mm
Width (B): 5 mm
Closures: Sealed (2RS)
Lubrication: Grease
Clearance: C0
Dynamic Load Rating (Cr) (Newtons): 410
Static Load Rating (Cor) (Newtons): 208
Weight: 0.005 kg
Quantity: 1 Lot = 1 PC
Special Note:
1 Sometimes the cages will be different.
eg.: 67 series thin-walled bearings because the inner wall is very thin will use the crown-shaped iron cage.
2 t
