2 wire
DC4.5-30V
This Red Voltage Meter withDC4.5-30Vrange. It is easy to read,install and use
And it is self-powered version and supports Reverse polarity protection.
When the voltage is under 10V,there will 2 readings after decimal point,which mean the accuracy is 0.01 when it is under 10V; when it is above 10v,the accuracy is 0.1
Mini RedLED display
No power supply needed
Measure Voltage: 4.5-30V two-wire access
Display: Three digit 0.56" LED,Red/Blue/Green
Refresh Speed: Approx.300mS/time
Highest input: 30V (higher than 30v has the risk of burn up)
Minimum input: 4.5V(below than 4.5V,measurement is inaccurate or does not show)
Minimum Resolution:0.01V(10V)
Resolution:1%plusmn1digit
Working Temperature:-20°~65°
Size:Approx. 48mm x 29mm x 22mm(L*W*H)
Hole Size: Approx.46*27mm
LED Color: Red/Blue/Green color
2 wire digital display voltage meter 0.56 inch LED digital voltmeter DC5V-120V
high-precision
Low start voltage,red minimum 5V,green minimum 5V,blue minimum 5V. It has reverse connection protection and does not burn when connected reversely
Ultra high withstand voltage 132v,no burning.
Measurement range: red dc5-120.0v,green dc5-120.0v,blue dc5-120.0v
Power supply range: no additional power supply is required,and the measured voltage is directly used as the power supply,and the range is the same as above
Maximum input: dc132v note: input voltage higher than 132v may cause permanent damage! Allowable error: ± 1%
Input impedance: > 100k
Refresh speed: about 300ms once
Display mode: three digit 0.56led digital tube
Display color: red,green and blue
Lead length: 20cm
Dimension: 48x29x22mm,length x width x thickness
Opening size 46x27mm
3-wire 0-30V
Measurement range: 0-30V
Minimum input: 0V
Maximum input: dc30 (over this voltage,it may be burnt out)
Allowable error: 1% (+ / - 1 word)
Display mode: 3-digit 0.56 "led nixie tube
Display color: red,green or blue
Refresh speed: About 200ms / time
Power supply: 3-30V
Current consumption: less than 20mA,generally 5-15ma
Working temperature: - 10 - 65
Dimension: 48mm * 29mm * 22mm
Opening size: 46 × 27mm
Lead length: 20cm
==========
Hign-concerned Chemical : None
Model Number : Digital Voltmeter
DIY Supplies : ELECTRICAL
Dimensions : 48mm x 29mm x 22mm(L*W*H)
Operating Temperature : -20°~65°
Accuracy Class : 1%
Power Supply :
Display Type : Digital Only
