بيت / LOXNVUY / مكونات سلبية
TL-N20MC1 مستشعر القرب الحثي، 3 أسلاك IP67 مسافة الاستشعار 10 مم مفتاح معدني NPN PNP NO NC 10-30VDC، قطعة واحدة (15 مم DC 3 أسلاك PNP NC) in Kuwait

15 مللي متر تيار مستمر 3 أسلاك NPN NC

KWD 18
ماركة
LOXNVUY
اللون15 مللي متر تيار مستمر 3 أسلاك NPN NC
– 1 +

مميزات خاصة

  • 【Non contact sensing, durable and long-lasting】;Multiple technologies including inductance, capacitance, and optoelectronics are available, eliminating the need for contact with the measured object, avoiding collision and wear, and extending the service life of equipment and sensors
  • 【High sensitivity anti-interference, zero misjudgment】:Adjustable sensing distance, built-in anti electromagnetic interference chip, fearless of dust and oil stains, precise detection without triggering false alarms
  • 【Multi specification full compatibility, full scene coverage】:Micro/standard/long-distance options available, compatible with DC 2/3/4 wires and AC 2 wires, universal for assembly line/limit/sorting
  • 【high protection, able to withstand harsh working conditions】:Stainless steel/engineering plastic shell, with a wide temperature tolerance of -25 ℃~70 ℃, dustproof, waterproof, and shockproof, suitable for use in both workshop and outdoor environments
  • 【Triple protection+easy installation, worry free and effortless】:Short circuit/overload/reverse connection protection to prevent burning out; Embedded/non embedded/bracket installation, compatible with M8-M30 threads, single person quick deployment

وصف

TL-N20MC1 Inductive Proximity Sensor, 3-wire IP67 Sensing Distance 10mm Metal Switch NPN PNP NO NC 10-30VDC, 1pc
High-concerned chemical : None
Theory : Inductance Sensor
Material : Metal
Output : Switching Transducer
Use : Position Sensor
Sensing distance : 15MM/20MM
Assured distance : 13.5MM/18MM
Protection degree : IP 67
Switching frequency : 500Hz
Connection : 2m PVC Cable
Supply voltage : 6-36VDC 3-Wires
Theory : Self-induction
Sensing surface size : 40*40mm
