Specification:
Sensor size: 1/1.8
Pixel size: 2.0*2.0μm
Output resolution: 3840*2160
Frame rate: HDMI+USB@30FPS
Image storage method: U disk or computer
Video: 1920*1080&3840*2160@30FPS
Exposure time: 0-999MS
Exposure: Auto and Manual, provides target brightness settings
White Balance: Auto and Manual
Parameter settings: contrast, saturation, gamma, sharpness, noise reduction, etc.
Working temperature: 0-60℃
Storage temperature: -20-85℃
Single machine weight: 0.5kg
8X-100X Zoom C-mount Lens:
Work distance: 40mm-400mm
Zoom ratios: 1:17
Magnification Power by 0.12 - 2X (about 8X - 100X on the Monitor)
view field of Max multiple : 5.4mm*3mm
view field of Min multiple : 54mm*3mm
Size: 115mm(L) * 40mm(DIA)
Weight: 210g
10X-180X C-MOUNT Lens:
Working distance: 90-150mm
Zoom ratios: 1:6.5
Magnification Power by 0.7 - 4.5X(about 10 - 180X on the display)
view field of Max multiple : 2.8mm*1.5mm
view field of Min multiple : 25mm*14mm
Eyepiece lense : 0.5X
Size: 168mm(L) * 50mm(DIA)
Weight: 600g
20X-300X C-MOUNT Lens:
Working distance: 90-180mm
Zoom ratios: 1:6.5
Magnification Power by 0.7 - 4.5X(about 20 - 300X on the display)
view field of Max multiple : 1.4mm*0.8mm
view field of Min multiple : 10mm*5mm
Eyepiece lense : 1X
Size: 245mm(L) * 50mm(DIA)
Weight: 630g
1X-130X C-MOUNT Lens:
Working distance: 50mm-1000mm
zoom ratios: 1 : 15
Magnification Power by 0.13- 2X (about 1 - 130X on the display)
view field of Max multiple : 4.2mm*2.4mm
view field of Min multiple : 130mm*70mm
Size: 30mm(diameter) * 99mm(length)
10X-200X C-mount Lens:
Working distance: 90MM-200MM
zoom ratios: 1 : 7.2
Magnification Power by 0.7- 5X (about 10 - 200X on the display)
view field of Max multiple : 3.2mm*1.8mm
view field of Min multiple : 37mm*21mm
Eyepiece lense : 0.4X
Size: 55mm(di
