Joyzan Worm Geared Motor, DC 12V Gear Box Reversible High Torque Reversed Turbine Electric Drive Reduction Window Door Lock Opener Miniature Winch Robot Rotating Table Curtain Machine 10KG.CM 62RPM

KWD 3.500

1 +

Special Features

  • High Torque Turbo Gear Motor: The DC 12v gear box no self locking, good operation, hardness material, good toughness, impact resistance, 12V DC worm gear motor improve bearing quality and service life of mini turbine geared motor, extremely
  • Vertical Arrangement: The worm gear motor shaft of the output shaft of the gearbox of the motor shaft is arranged vertically, engine mini turbine worm motor is convenient for your work and easy to install, in this case, this reversible high worm geared motor can fully save your time and energy
  • Installation Size Adaptation: The entire electric drive motor output shaft body is short, compared with the general direction of the gear motor, 12V reducer electric motor is widely adapted to some installation size requirements in this regard, this high torque DC motor is your good helper
  • No Load Speed Selection: Turbo worm geared motor no load speed selection is 5rpm, 6rpm, 20rpm, 40rpm, 62rpm, turbine worm gear box reduction motor can be selected according to your needs
  • Widely Used Motor: This high torque worm gear motor, turbine electric gearbox motor short type can be widely used in windows, remote control curtains, micro door openers, barbecue grills, ovens, washing machines, garbage disposals, coffee machines, printing presses, household appliances, micro winches and other occasions is your ideal

Description

Features:
1. The high torque rotation motor with speed control no self-locking, working well
2. The DC high torque motor, micro worm geared motor output shaft direction of the motor shaft is arranged vertically
3. This DIY mini geared motor is suitable for widely used in windows, a door opener, miniature winch and other occasions
4. The dc gearbox output shaft direction of the high torsion speed reduce electric motor shaft is arranged vertically
5. High torque speed reduction motor has five speed choice are 5rpm, 6rpm, 20rpm, 40rpm, 62rpm

Specifications:
Voltage: DC12V
Load torque: 10KG.CM
No Load Speed Choice : 5rpm / 6rpm / 20rpm / 40rpm / 62rpm(optional)

Speed(RPM) Stall Torque(kg.cm) Stall Current(A) No-load Current(A) Reduction Ratio
5 36.4 0.82 0.12 1:972
6 36.4 0.82 0.12 1:972
20 28.2 1.14 0.22 1:400
40 15 1.15 0.31 1:224
62 16 2.52 0.41 1:224

Package contain:
1 x Geared Motor
