Printer Specifications

Resolution
203 dpi/8 dots per mm
Memory
128 MB SDRAM memory
128 MB on-board linear Flash memory
Maximum Print Width
4.09"/104 mm
Maximum Print Speed
6"/152 mm per second
Media Sensors
Transmissive and reflective sensors
Media Characteristics
Maximum label and liner width: 4.5"/114 mm
Maximum non-continuous label length:39"/991 mm
Media Width
0.75"/19.4 mm to 4.50"/114 mm
Print Length
203dpi: 157"/3,988 mm
Maximum Media Roll Size
8.0"/203 mm O.D on a 3.0"/76 mm I.D. core
6.0"/152 mm O.D. on a 1.0"/25 mm I.D. core
Media Thickness
0.003"/0.076 mm to 0.010"/0.25 mm
Media Types
Continuous, die-cut, notch, black mark
Barcode Symbologies
Linear barcodes: Code 11, Code 39, Code 93, Code 128 with subsets A/B/C and UCC Case Codes, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN with 2 or 5 digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar, Planet Code
2-Dimensional: Aztec, Codablock, PDF417, Code 49, Data Matrix, MaxiCode, QR Code, MicroPDF417, TLC 39, RSS-14 (and composite)
Communication
ZebraNet a/b/g/n Print Server (internal)
ZebraNet 10/100 Print Server (internal or external)
Centronics Parallel port (internal)

Dimension
9.5 in. L x 10.9 in. W x 17 in. H
Weight
20 lbs./9.1 kg
