Speed Reducer 130mm Planetary Gearbox Ratio 3:1 4:1 5:1 6:1 8:1 Input 22mm Output 22mm 90N.m for 130 Servo Motor(8 to 1) in Kuwait Speed Reducer 130mm Planetary Gearbox Ratio 3:1 4:1 5:1 6:1 8:1 Input 22mm Output 22mm 90N.m for 130 Servo Motor(8 to 1) in Kuwait Speed Reducer 130mm Planetary Gearbox Ratio 3:1 4:1 5:1 6:1 8:1 Input 22mm Output 22mm 90N.m for 130 Servo Motor(8 to 1) in Kuwait Speed Reducer 130mm Planetary Gearbox Ratio 3:1 4:1 5:1 6:1 8:1 Input 22mm Output 22mm 90N.m for 130 Servo Motor(8 to 1) in Kuwait Speed Reducer 130mm Planetary Gearbox Ratio 3:1 4:1 5:1 6:1 8:1 Input 22mm Output 22mm 90N.m for 130 Servo Motor(8 to 1) in Kuwait

4 to 1

KWD 142
Brand
YJHQJNLE
Weight
2 kg
Size4 to 1
– 1 +

Special Features

  • High-efficiency transmission: all through the gear precision meshing to reduce energy loss; suitable for long-term high load operation
  • Compact structure: space-saving design reduces the size of the reducer; suitable for narrow installation environments
  • Flexible transmission ratios: wide range of single-stage ratios; higher ratios can be realized with multi-stage combinations; suitable for diverse needs
  • Stable operation and low noise: low continuous vibration; reduced impact; low noise
  • High load and long service life: long service life; reduce maintenance cost

Description

Input Speed : 3000rpm
Output Torque : rated load 90N.m, max 150N.m
Model Number : PX130NServo-stage1
Gearing Arrangement : Planetary
Backlash : no more than 20arcmin
Lifetime : Nomally 20000h
