TX12 MKII 16CH OpenTX and EDGETX Multi-Module Compatible Digital Radio Transmitter for RC Drone
TX12 MKII internal RF system integrates Corona, Hitec, Futaba S-FHSS, Frsky D16/D8, RadioLink and Graupner HoTT RF chip modules on one board
The internal RF module of Radio Master will directly support firmware updates from the radio operating system. There is no complicated update process. TX8 comes with Deviation TX software installed as standard
Radio Firmware: EdgeTX (Transmitter) / ExpressLRS (RF module)
Upgrade Method: USB/SD card & EdgeTX Buddy online or EdgeTX Companion PC software

Mode 1-Right-hand throttle

Mode 2-Left hand throttle

New to TX12 MKII

Updated rear case with comfortable grips

Improve S1 / S2 Grips

Improved USB-C QC 3.0 Charging

Updated main board design

Updated MCU to STM32F407

EdgeTX factory installed

SD Card included

Internal ExpressLRS RF Module

Specifications:

Size: 170*159*108mm

Weight: 363g

Frequency: 2.400GHZ-2.480GHZ

RF Chip option: ExpressLRS (ELRS)

Transmitting Power: 20dbm

Antenna Gain: 2db

Working Current: 320mA@8.4V

Voltage Range: 6.6-8.4v DC

Range: > 2km (depending on receiver)

Radio Firmware: EdgeTX (Transmitter) / ExpressLRS (RF module)

Channels: Up to 16 (depending on receiver)

Display: 128*64 Monochrome LCD display

Gimbal: High precision hall gimbals

External module: JR/FrSKY/Crossfire compatible

Upgrade Method: USB/SD card & EdgeTX Buddy online or EdgeTX

Companion PC software

USB Charging: QC3 USB-C

SD Card: Included
