ATC Power Module
Performance
7 Pin SIP International Standard Pin
Isolation voltage: 1500VDC
Low quiescent current and high conversion efficiency
Low ripple factor and low noise
Operating ambient temperature: -40-+85
MTBF3.5 million hours (3500000Hrs)
Output short-circuit protection: sustainable short-circuit protection, automatic recovery
Built-in soft start technology
Special specification products can be designed according to customers' requirements
The IB_S-2WR3 series is designed to be used in distributed power supply systems that need to generate power applications that are isolated all the way from the input power supply.
This product is suitable for:
The voltage of the input power supply is relatively stable (voltage variation range ±5%Vin);
Isolation is required between input and output (isolation voltage 1500VDC);
Occasions with high requirements for output voltage stability and output ripple noise;
Typical applications: pure digital circuits, general low-frequency analog circuits, relay drive circuits, data exchange circuits, etc.
