16x24 Pneumatic Dual Platen Heat Press Machine with Infrared Positioning, Auto Up-Sliding, Digital LCD, Adjustable Pressure, White+Blue, for T-Shirts, Ceramics, Mousepads & MoreExperience unmatched efficiency and precision with the 16x24 Pneumatic Up-Sliding Heat Press Machine. Designed for high-volume production and professional-grade applications, this heat press features dual platen operation, infrared laser positioning, and a pneumatic system that enhances printing accuracy and ease of use. Its heavy-duty aluminum frame and slide-out lower platen ensure a stable, safe, and seamless workflow.
Pneumatic Dual Platen System: Powered by an air compressor (not included), this machine automates the pressing process with up to 0.8Mpa adjustable pressure for consistent, professional results.
Infrared Positioning: Laser-guided positioning ensures precise alignment for logos, designs, or patterns on garments and hard surfaces.
Digital LCD Controls: Full control over temperature, time, and count settings with a large LCD display—ideal for repetitive and timed operations.
Up-Sliding Design & Dual Stations: The dual-station setup with smooth sliding rails allows simultaneous prep and press, increasing efficiency and output.
Heavy-Duty Build with Base Frame: Aluminum construction with a separate stand for the lower plate, silicone mats for even pressure, and brake casters for easy movement and stability.
Voltage: 110V / 60Hz
Power: 1.6KW
Temperature Range: 0–299°C (32–570°F)
Timer Range: 1–999 seconds
Max Pressure: 0.8Mpa
Max Item Thickness: 2.36 inches
Heat Plate Size: 16 x 24 inches (40 x 60 cm)
Assembled Size: 35” L x 33” W x 52” H
Weight: 284.45 lbs (G.W. 306.5 lbs)
Package Dimensions: 42.52” x 33.86” x 32.28”
Pure Cotton: 356°F–428°F (180–220°C), 15–25 seconds
Polyester: 356°F (180°C), 40 seconds
Chemical Fiber: 302°F–356°F (150–180°C), 10–40 seconds
Pearl Board: 356°F (180°C), 60–100 seconds
Metal Pendant: 356°F (180°C), 60 seconds
Mousepad: 374°F (190°C), 50 seconds
Vitrolite: 392°F (200°C), 180 seconds
Ceramics: 356°F–428°F (180–220°C), 180 seconds
1 x 16x24 Pneumatic Dual Platen Heat Press Machine
1 x Air Compressor Hose
1 x Lubricating Bottle for Air Cylinder
1 x Power Cord
1 x Emergency Stop Button
1 x User Manual
Whether you're printing on T-shirts, ceramics, metal pendants, or mousepads, this advanced pneumatic heat press delivers consistent and high-quality results—ideal for workshops, studios, and growing businesses.
