Universal RC FPV Drone Flight Controller 25.5X25.5mm F411ELRS AIO ICM42688P OSD BLHELIS 12A 4in1 ESC ELRS 2.4G Compatible with 1-2S Models

KWD 34.500
Brand
SKorFGX
Weight
400 g
– 1 +

Special Features

  • Versatile: Compatible with a wide range of RC FPV drones, enhancing your flying performance.
  • Efficient: Features a 25.5x25.5mm F411ELRS AIO design, optimizing space and integration.
  • Advanced: Equipped with ICM42688-P Compatible With superior stability and responsive flight control.
  • Integrated: Includes BLHELI_S 1-2S 12A 4in1 ESC Compatible With streamlined electronic speed control.
  • Reliable: ELRS 2.4G ensures robust long-range communication Compatible With uninterrupted flights.
  • Compact: Designed with M3 mounting holes, fitting into your drone setup.
  • Enhanced: Integrated OSD Compatible With real-time data, allowing Compatible With precise and informed piloting.

Description

Model: F411ELRS
Main Control Chip: STM32F411CEU6 (100MHz, 512K)
Gyroscope: ICM-42688-P
OSD Chip: AT7456E
Programming: Supported
BB Ring: Supported
Input Voltage: 1-2S
I2C Interface: Supported
BEC Output: 5V/1.5A and 9V/2A
Camera Input: Supported
Serial Control Port: Two (UART1 compatible with internal ELRS receiver and external SBUS, UART2 compatible with diagram)
Flight Control Firmware: Betaflight 4.4.3 JHEF411.HEX
Current: 12A * 4
Current Meter: Yes
Firmware: BLHELI_S Z-H-30.HEX
Support Compatible With Blue Bird: 24K, 48K, 96K
Default Electrical Driver Protocol: DSHOT300
Receiver Type: ELRS
Receiving Frequency: 2.4G
Receiver Protocol: CRSF
Receiver Firmware: EP24. V3.2.0
Wi-Fi Update Compatible With ELRS Firmware: Supported
Independent Receiver: Yes (non-SPI method)
Mounting Dimensions: M3, 25.5*25.5mm
Maximum Dimensions: 30*30mm
Weight: 4.9g
Compatible with RC FPV Drones 25.5X25.5mm.
