*** Specifications:
Battery Support: 2S LiPo batteries
BEC Output: 5.5V/7.4V, 5A
Constant Current: 25A
Burst Current: 50A
Built-in Power Switch: Integrated for convenience
Dimensions: 0.71 x 0.55 x 0.37 (inch), 18.1 x 14 x 9.5 (mm)
Weight: 7.6 grams (0.27oz)
*** Features:
Support Sensored/Sensorless 25A/50A ESC
Live tunning on Furicar app
Super ridiculously smooth throttle control
Mini size and light weight
Super easy programming via App on both Android and iOS
Real-time telemetry up to 10Hz
FREE lifetime firmware updates
*** Advantages:
Plug&Play: Just buy it, plug it in, and use it—no soldering skills required.
Very Compact and Lightweight: The MICROBEAST ESC's small size and light weight make it easy to install and ideal for maintaining the agility of your RC car.
High Current Capability: Handles high currents without the need for a cooling fan, ensuring reliable performance under demanding conditions.
Versatile Operation: Compatible with both sensored and sensorless motors, offering flexibility for different RC setups.
Multiple BEC Voltage Options: Provides selectable BEC output levels to match various servo requirements, enhancing compatibility and performance.
**** FURITEK STORM RAZOR SENSORED MOTOR:
*** Motor Specifications:
Motor Type: Sensored
Motor Kv: 9500
Battery: 2S
Resistance: 0.042ohm
Max Current: 8A
Slot/Pole: 12 slot/4 pole
Shaft: 2*10mm
*** Motor Features:
Sensored 4-pole hi-torque motor design.
High purity and higher temperature single copper windings ---lower copper losses, very good heat dissipating--maximizes efficiency.
Super thin stator laminations---lower eddy losses---maximizes efficiency. Japanese NMB --High RPM ABEC5 bearings.
Precision balanced rotor, smoothness for best reliability and maximum RPM. CNC machined 6061 T6 billet aluminum heatsink can.
Precision engineered for maximum energy conversion.
*** Pinion included:
Gear 0.5M-11T-Steel-Black
*** Package Includes:
1x Furitek 25/50A MICROBEAST Sensored/Sensorless ESC
1x Furitek wireless module
1x Furitek Storm Razor motor with 11T Steel pinion
1x User Manual
1x Sensored Cable for Furitek Storm Razor motor
1x Signal Cable
*** Extra requirement:
- Require a new 2-channel TX/RX system. It is not compatible with stock TX/RX
- A good 0.9mm allen key wrench tool is required
