JMT 1 to 2 RJ45 Unmanaged Ethernet Switch 3-Ports 1000Mbps Compatible with MDI/MDIX USB-C Power Supply
Description
TXE308 is a 3-ports 10/100/1000Mbps unmanaged ethernet switch provides the seamless network connection. Providing 3x10/100/1000Mbps RJ45 ports, and each port has MDI/MDIX cross detection function. Using store and forward technology, combined with dynamic memory allocation, to ensure the effective allocation of bandwidth to each port.
Features:
Comply with IEEE802.3¡IEEE 802.3u¡IEEE802.3ab¡IEEE802.3x¡IEEE802.1q¡ IEEE802.1P standards;
Support 8 x10/100/1000Mbps Auto-negotiation RJ45 ports , all port auto MDI/MDIX;
Supports IEEE802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode;
8K entry MAC address table of the switch with auto-learning and auto-aging;
Adopting external power supply and exquisite iron shell design. suitable for desktop install and use.
Detail:
Interface: 3x 10/100/1000Mbps Auto-Negotiation ports
Transfer Method: Store-and-Forward
MAC Address Table: 8K
Switching Capacity: 10Gbps
Packet Forwarding Rate: 7.44Mpps
Packet buffer: 4M bits
Jumbo frame: 15K Bytes
Power Consumption: 1.01w (MAX)
Indicators:
Per Device: Power (Green)
Per Port: Link/Activity (Green)
Environment:
Operating Temperature: 0¡ãC~40¡ãC
Storage Temperature: -40¡ãC~70¡ãC
Operating Humidity: 10%~90% non-condensing
Storage humidity: 5%~90% non-condensing
Network Media:
10Base-T: UTP category 3, 4, 5 cable (max 100m)
100Base-Tx: UTP category 5, 5e cable (max 100m)
1000Base-T: UTP category 5, 5e cable (max 100m)
