Transceivers
2.5G SFP 1550nm 80KM DOM Dual LC Connector Transceiver

Please Mark the of Your Switches Need to be Compatible With!

The SFP transceivers are high performance, cost effective modules supporting dual data-rate of 2.488Gbps/2.125Gbps and 10km transmission distance with SMF. The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement () and SFF-8472. For further information, please refer to SFP .

Features

Dual data-rate of 2.488Gbps/2.125Gbps operation

1310nm DFB laser and PIN photodetector for 10km transmission

Compliant with SFP and SFF-8472 with simplex LC receptacle

Digital Diagnostic Monitoring: Internal Calibration or External Calibration

Compatible with SONET OC-48 system

Compatible with +3.3V single power supply

Operating case temperature: Standard : 0 to +70°C

Application

SDH STM-16 and SONET OC-48 system

Fiber Channel

Switch to Switch interface

Switched backplane applications

Router/Server interface

Other optical transmission systems
