Special Features

2x SO-DIMM DDR4 3200MHz (compatible with 2400/2666) Max 64G
1x M.2 NVMe (PCle 3.0x2) interface Compatible with 2280 size solid state hard disk
1x M.2 WiFi A.E Key Support WiFi6/Bluetooth module M.2WiFi socket can expand M.2.NVMe adapter board, the original M.2 signal becomes X1 after use
2x SATA3.0 interfaces, 4pin power supply compatible with 2.5/3.5 inch hard drives
1x HDM11.4+DP1.2a+Type-C display/data, support 3 display outputs
1x TF card holder, support data storage and system boot function Onboard 2 small 3/4Pin 12V fan sockets Reserve a set of TPM pin headers
BIOS: AMI UEFI BIOS autostart, GPIO, watchdog, PXE.....

Description

CPU: Intel Celeron Elkhart Lake J6412
Memory: 2 * SO-DIMM DDR4 3200MHZ single maximum 32C (compatible with 2400/2666MHz)
Storage: 1*M.2 NVMe 2*SATA3.0
Graphics: 10th Generation Intel UHD Graphics
Network card: 4 * Intel i226-V 2.5G
Display: 1*HDMI 1.4 1*DP 1.2a 1*Type-C
USB: 2* USB3.0 2* USB2.0
Heat dissipation: no fan, pure copper heat conduction aluminum shell passive heat dissipation
BIOS: AMI UEFI BIOS autostart, GPIO, watchdog, PXE
TDP: 10W
Power supply: DC12V 100-240V50/60Hz (5.5*2.5 connector)
Chassis: aluminum alloy material
Expansion header: 1*4pin CPUFAN fan terminal 1*USB header 1*TPM header
Dimensions: 178.3mm(L) * 126.5mm(W) * 55mm(H)
Feature: The M.2 WiFi socket can be converted to NVMe signal with an adapter board
Dimensions: 178.3mm(L) * 126.5mm(W) * 55mm(H)
Color: Black/Iron Gray
Installation method: desktop, wall-mounted (you can contact customer service to purchase additional wall hangings)
Working environment: -0°C~+70°C relative humidity 5%-85%
