Please note: This is a barebone only. A system memory, a storage drive and an operating system are needed to complete this system
Model Number: HUNSN RJ50f
Chassis: Aluminum
CPU: Intel i5-1240P Processor 12M Cache, up to 4.40 GHz
AES-NI Supported: Yes
Memory: 2 x SODIMM Up to DDR5 4800 MT/s, max. 64GB RAM
Storage: 1 x M.2 2280/22110 PCIe4.0 NVME x4 SSD, not support internal SATA SSD/HDD,
support knock-out holes DIY for external 2.5 Inch or above SATA SSD/HDD
I/O Interface: Power ON/OFF, Audio, 2 x HDMI2.0, TF for data storage/system boot, DP++1.4, 2 x USB2.0, RST,
10Gbps Type-C for data/DP 4096x2160@60Hz, 5Gbps Gen1 USB3.2, Console, DC_IN, 4 x LAN, 2 x SFP+ Optical
Network Card: 4 x Intel 2.5GbE I226-V, 2 x SFP+ Optical, the sfp model is 10Gbe 82599ES
WAN-LAN Throughput: Throughput through 2.5 gigabit nic from lan to wan forwarding speed is 2.5Gbps
Throughput through 10 gigabit optical from lan to wan forwarding speed is around 5Gbps or more
Expansion Pin: 1 x GPIO, 1 x TPM, 1 x Phoenix terminal power supply socket, 2 x USB2.0
Power: DC100-240V AC/50-60hz, DC 12V-19V wide voltage, 12V10A
Operating Temperature: -0°c~70°c
Relative Humidity: 5%~85% non-condensing
TDP: 20-64W
Cooling System: Dual copper tube turbo fans for active cooling
Size: 154.6x 131.7 x 60mm
Weight: 1.6kgs
Packing List: HUNSN RJ50f firewall appliance, power supply, power cord, warranty card
System Compatibility: 5.10.x and above core-based freebsd router systems, linux distros, or win.os supported.
Compatibility: firewalls for pfsense plus, opnsense and other popular open-source software solutions
