1. Introduction
This extender uses WiFi to extend high-definition TV signals and USB keyboard and mouse signals up to 200 metres, with a resolution of up to 1920×1080P@60Hz. It not only breaks the distance limitations of HDMI cables but also eliminates the hassle of wiring, making it more convenient. This HDMI extender uses an HDMI (High-Definition Multimedia Interface) connector. If an HDMI-to-DVI adapter is used, it also supports DVI (Digital Visual Interface) connectors, providing greater flexibility and more options for home theatre systems. It offers multiple solutions for home users, such as high-definition TV sales and demonstrations, set-top boxes, DVD players, projectors, and other devices, as well as applications in space and security fields, data control centres, information dissemination centres, meeting rooms, schools, and corporate training environments.
2. Operating Steps
1) First, connect the display device directly to the signal source player via an HDMI cable to check for signal output and normal display;
2) Connect the HDMI cable and USB Type-C cable to the sender's HD IN, USB IN, and host;
3) Connect the receiver's HDMI cable to the display device and the sender to the signal host;
4) Connect the mouse and keyboard to the USB ports on the receiver;
5) Power on the sender and receiver;
6) When using the wireless extender for the first time, pairing is required: press the pairing button ‘Pair' on the receiver for over 5 seconds, then press the pairing button ‘Pair' on the sender for over 3 seconds. The extender will automatically enter pairing mode until pairing is complete.
6. Packaging Contents
1) Transmitter x1
2) Receiver x1
3) DC 5V power adapter x2,
4) USB Type-C data cable x1,
5) IR infrared receiver cable x1,
6) IR infrared transmitter cable x1.
7) User manual x1
