Camera Module
Image Sensor: 1/2.5" progressive scan CMOS
Min. Illumination: Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0.001Lux @(F1.6, AGC ON),0 Lux with IR
White Balance: Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
Digital Zoom: 16×
Privacy Mask: 24 programmable privacy masks
Focus Mode: Auto/Semi-automatic/Manual
WDR: 120 dB WDR (not supported by full frame rate)

Lens
FOV: Horizontal field of view: 59.5° to 2.6° (Wide-Tele), Vertical field of view: 35.7° to 1.5° (Wide-Tele), Diagonal field of view: 66.6 to 3.0° (Wide-Tele)
Zoom Speed: Approx. 3.6 s (optical lens, wide-tele)
Working Distance: 10 mm to 1500 mm (wide-tele)
Aperture Range: F1.6 to F3.5
Focal Length: 4.8 mm to 120 mm, 25× optical zoom

Image Enhancement: HLC/BLC/3D DNR/Defog/EIS/Regional Exposure/Regional Focus
Interface
Audio Input/Output: 1-ch/1-ch
Network Interface: 1 RJ45 10 M/100 M Ethernet, PoE+ (802.3 at, class4)

PTZ
Movement Range (Pan): 360° endless
Movement Range (Tilt): From -15° to 90° (auto-flip)
Speed: Configurable, from 0.1°/s to 80°/s,Preset Speed: 80°/s
Proportional Zoom: Support
Presets: 300
Patrol Scan: 8 patrols, up to 32 presets for each patrol
Power-Off Memory: Support
Park Action: Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan
PTZ Status Display: Support
Preset Freezing: Support
Scheduled Task: Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust/Aux Output

General
Material: ADC 12, PC+10% GF
Dimensions: Φ 164.5 mm × 290 mm (Φ 6.48" × 11.42")
Weight: Approx. 2 kg (4.41 lb)
Power: 12 VDC, 2.0 A and PoE (802.3 at), 42.5 to 57 VDC, 0.6 A, class4; Max.: 18 W, including max. 7W for IR
