Novastar VX400 All-in-One Controller Specifications:
The VX400 is NovaStar's new all-in-one controller that integrates video processing and video control into one box. It features 4 Ethernet ports and supports video controller, fiber converter and Bypass working modes. A VX400 unit can drive up to 2.6 million pixels, with the maximum output width and height up to 10,240 pixels and 8192 pixels respectively, which is ideal for ultra-wide and ultra-high LED screens. The VX400 is capable of receiving a variety of video signals and processing high-resolution images. In addition, the device features stepless output scaling, low latency, pixel-level brightness and chroma calibration and more, to present you with an excellent image display experience. What's more, the VX400 can work with NovaStar's supreme software NovaLCT and V-Can to greatly facilitate your infield operations and control, such as screen configuration, Ethernet port backup settings, layer management, preset management and firmware update. Thanks to its powerful video processing and sending capabilities and other outstanding features, the VX400 can be widely used in applications such as medium and high-end rental, stage control systems and fine-pitch LED screens..

VX400 FEATURE:
Low latency:
Reduce the delay from the input to receiving card to 20 lines when the low latency function and Bypass mode are both enabled.

2x layers − Adjustable layer size and position
− Adjustable layer priority

Output synchronization
An internal input source can be used as the sync source to ensure the output images of all cascaded units in sync.

Powerful video processing
− Based on SuperView III image quality processing technologies to provide stepless output scaling
− One-click full screen display
Relevant configuration software and instructions are available! Please fell freely to contact Shenzhen Artpixel Technology Co.,ltd.
