OPTICAL PORT: Gigabit Ethernet,SC Standard,1310nm wavelength, Connect Singlemode Dual Fiber Cable, 40km Transmission Distance
RJ45 PORT: 10/100/1000M, Full duplex-flow control, Half duplex-back pressure; Connect UTP CAT5 Cable,Supports MDI/MDI-X auto sensing.
STANDARD: Complies with IEEE IEEE 802.3/802.3u/802.3z/802.3ab. The LED indicators for TX, FXL/TXL,POWER, FDX can dynamic feedback link connection state and fault detection to easily monitor network status.
AVAILABLE FOR CHASSIS: Can work with 2U 19" 14 slots chassis,support wide power supply voltage (100V-240V).Standalone operating voltage is 5VDC /1.0A.
WHAT YOU GET: 1pc 40km Gigabit Fiber Optical Converter; 1pc power supply; one-year warranty, 30 Days free-returned, free Lifelong technology support.

وصف

Main Features
10/100/1000Mbps autosensing, auto-MDI/MDIX
Auto-MDI/MDIX copper RJ45 port
Link fault pass through (LFPT)
1600byte super data packet transmission
Full duplex-flow control, half duplex-back pressure
Full- positioned LEDs to indicate power and network status
Standard : IEEE802.3 (10BASE-T), IEEE802.3u 100BASE-TX/FX (Fast-Ethernet), IEEE802.3x (Flow Control), IEEE802.1q, IEEE802.1p QoS, IEEE802.1d Spanning Tree

Ethernet port
Copper RJ45 port
10/100/1000M Auto-sensing
Optical Port
Gigabit SC Connector
MM, 500m, SC connector, 850nm
SM, 40km, SC connector, 1310nm
SM, 60km, SC connector, 1550nm
SM, 80km, SC connector, 1550nm
Specification
Conversion Mode / Delay Time:Store-and-Forward
Dimensions : 2.76 inch*3.66 inch * 0.98 inch (W*D*H)
Weight：0.3 kg
Input Voltage：DC5V1A with External power adapter
Power Consumption：
MTBF：50,000 hours
BER：
MAC Address Table：1K
Buffer Size：128K
Operating Temperature：0℃-50℃
Storage Temperature：-40℃-70℃
Storage Humidity：5%-90% non-condescending
Warranty
One year
