Color: white

Features:
Handware Specification: MT7620A+MT7612E Chipset
RAM: 64MB; FLASH 8MB
Antenna: 2*4dBi External Antenna (Fixed)
Wireless Standard: IEEE802.11ac/a/b/g/n
Button: 1*WPS/RST Button
Physical Ports: 1*10/100Mbps LAN RJ45 Ethernet Port
Power: 100~240V, 50/60Hz
Channel Bandwidth: 20/40/80 MHz Auto
Encryption: WPA-PSK / WPA2-PSK; WPA/WPA2

Frequently Asked Questions:
Q1. Why can't I open the IP address: 192.168.10.1
A1. Make sure your computer is connected to the Extended network SSID or connect your computer to the Device using an Ethernet cable.
A2. Make sure your computer is set to obtain an IP address automatically
A3. Verify that 192.168.10.1 is correctly entered in the web browser and press Enter

Q2. Why can't I access the network after successful setting?
A1. You may have inputted the router's password incorrectly during setting the extender. The password of the router and WiFi extender must be the same. Please reset the WiFi extender and go through the configuration.
A2. The WiFi extender maybe out of range, please move it closer to the router which should be less than 35 feet.
A3. Please change your router channel to channel 11 and reset the extender.

Q3. How to change the channel of my router?
A. Use a wireless device, connect to your router WiFi, then open a browser in this device, enter your router's ip address in the address bar of the browser
Click "Wireless Settings" and "Channel"
Choose channel 11

Package List:
1 x 1200Mbps WiFi Range Extender
1 x RJ-45 Networking Cable
1 x Quick Installation Guide
