Please note: This is a barebone only. A system memory, a storage drive and an operating system are needed to complete this system
Model Number: HUNSN RN04
CPU: Intel Xeon Processor E5-2640 v4 25M Cache, 2.40 GHz not support turbo boost
AES-NI Supported: Yes
Chipset: Intel C612
Memory: 2 x SODIMM DDR4 2400 MT/s, MAX.64GB RAM
Storage: 2 x M.2 2280 NVME SSD
Network Card: 2 x SFP28 25GbE Intel E810 XXVDA2, 8 x 2.5GbE 226-V LAN
I/O Interface: 2 x SFP28 25GbE, CLR CMOS, 4 x USB3.0, Console, 8 x 2.5GbE LAN, VGA ASPEED AST2400, RST,
Power Switch, AC Socket
Expansion: Mini PCIE for WiFi, M.2 for WiFi share the signal with Mini PCIE, 2 choose 1,
Mini PCIE for 4G, with SIM slot, PCIe 3.0 x8 slot
Chassis: 1U 19 inch cabinet, rackable, with mounting bracket ears, wall hanging, foot pad
Power: 100-240V 200W, support 12-24V
Operating Temperature: -0~+50°C commercial HDD, -20°C~+50°C industrial SSD, surface air flow
Ambient Temperature: 5%~90% non-condensing
TDP: 90W
Cooling System: The processor uses the ball silent cooling fan to ensure the long time work and stable cooling
Size: 440 x 410 x 47mm
Weight: 5.4kgs
Packing List: HUNSN RN04 firewall appliance, rackable ears, power cord, warranty card
Function: Supports hardware auto power on enabled default, Scheduled boot, Wake-up on LAN, PXE boot, Watchdog
System Compatibility: 5.10.x and above core-based freebsd router systems, linux distros, or win.os supported
Compatibility:firewalls for pfsense, opnsense and other popular open-source software solutions, uefi support only
