General
Operating voltage: 12V DC Car Battery
Set Weight: 2.5Kg/ 5.6lb
Chassis Dimensions WxHxD: 178mm x 50mm x 158mm/ 7 x 2 x 6-1/4 inch
Weight: 1.3kg/ 2.9lb
Monitor Dimensions WxHxD: 262mm x 181mm x 52mm/ 10-5/16 x 7-1/8 x 2-1/16 inch
Weight: 1.1Kg/ 2.4lb

Monitor Section
Picture size: 10.1 inches(diagonal) wide
W x H: 223.7 x 125.8 (mm), 8-13/16 x 4-15/16 (inch)
Display system: LCD panel
Drive system: TFT active matrix system
Number of pixels: 2,764,800, 1280H x 720V x RGB
Effective pixels: 99.99%
Pixel arrangement: RGB striped arrangement

USB I/F Section
Connector Type: Type-C
USB Standard: USB2.0 High Speed
File System: FAT 16/32, exFAT, NTFS
Maximum Power Supply Current: DC5V=3.0A
Audio Decoder: MP3 / WMA / AAC / WAV / FLAC / Vorbis
Video Decoder: MPEG1/2,MPEG4 / WMV / H.264 / MKV

Bluetooth Section
Technology: Bluetooth Ver5.2
Frequency: 2.402 – 2.480 GHz
Maximum Communication range: Line of sight approx. 10m (32.8ft)
Audio Codec: SBC / AAC / LDAC

Digital FM
Frequency Range: 87.9MHz - 107.9MHz (Frequency step)(200kHz)
Frequency Response: 20Hz - 20kHz (±3.0 dB)
S/N: 80dB (STEREO)

Digital AM
Frequency Range: 530kHz - 1700kHz (Frequency step)(10kHz)
Frequency Response: 40Hz - 15kHz (±3.0 dB)
S/N: 80dB (STEREO)

FM
Frequency Range: 87.9MHz - 107.9MHz (Frequency step)(200kHz)
Usable sensitivity: 7.3dBf
S/N 30dB: 0.7μV/75Ω
Frequency response (±3
