Camera Image Sensor 1/3" Progressive Scan CMOS Min. Illumination Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR Shutter Speed 1/3 s to 1/100,000 s Slow Shutter Yes Auto-Iris No Day & Night IR Cut Filter Digital Noise Reduction 3D DNR WDR 120dB 3-Axis Adjustment Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° Lens Focal Length 2.8 to 12 mm Lens Type Motorized Aperture F1.6 Focus Auto FOV horizontal FOV: 104° to 29° vertical FOV: 55° to 17° diagonal FOV: 125° to 34° Lens Mount Φ14 IR IR Range Up to 164ft(50 m) Wavelength 850nm Compression Standard Video Compression Main stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 H.264 Type Main Profile/High Profile H.264+ Main stream supports H.265 Type Main Profile H.265+ Main stream supports Video Bit Rate 32 Kbps to 16 Mbps Smart Feature-set Behavior Analysis Line crossing detection, intrusion detection Face Detection Yes Region of Interest Support 1 fixed region for main stream and sub-stream Image Max. Resolution 2688 × 1520 Main Stream 50Hz:25fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080) 60Hz: 30fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080) Sub-Stream 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) Third Stream 50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288) 60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) Image Enhancement BLC/3D DNR/HLC Image Settings Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser Day/Night Switch Day/Night/Auto/Schedule/Triggered by Alarm In Network Network Storage Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR Alarm Trigger Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error Protocols TCP/IP, ICMP, HTTP, H
