This compound microscope has a 45° inclined monocular head that reduces neck and eye strain. The WF 10x and WF 20x eyepieces are interchangeable, allowing for increased magnification from 40x—2000x.
The 40xR and 100xR objectives are retractable and spring-loaded to prevent damage to slides and objectives when focusing. It is also sealed to protect against further damage that can be caused from contact with liquid or oils. For added safety, it is equipped with a rack-stop which helps to prevent damage to slides and objective lenses, while the slip-clutch system protects gears from damage.
Brightfield LED illumination illuminates the specimen from below, making the specimen appear bright, but much darker than the bright background. This allows the darker specimen to be contrasted by the surrounding bright viewing field.
Specifications
Head: Monocular, 45° inclined, rotates 360°
Eyepiece: WF 10x with scale pointer, WF 20x eyepiece
Magnification: 40x, 80x, 100x, 200x, 400x, 800x, 1000x, 2000x
Nosepiece: Revolving reversed quadruple objective
Objective Lens: 4x, 10x, 40xR, 100xR oil DIN achromatic
Stage: Built-in, double-layer mechanical stage (140mm x 140mm), smooth X/Y calibrated movement with cross travel range 75mm x 50mm
Focusing: Coaxial coarse and fine focusing
Condenser: 1.25 NA Abbe lens
Diaphragm: Iris diaphragm with a swing-out filter holder
Light Source: LED illumination with intensity control
Power: 110V corded with cord wrap
Packing List
Monocular compound microscope with LED illumination
One 10x widefield eyepiece with calibrated pointer
One 20x widefield eyepiece
4x, 10x, 40xR, 100xR objectives
Immersion oil for 100xR objective
Double layer, built-in mechanical stage with 2 Stage clips
One dust cover
