Specification
Camera
Image Sensor： 1/2.8″ Progressive Scan CMOS
Max. Resolution 3840 × 2160 Min. Illumination： Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
Shutter： Speed 1/3 s to 1/100,000 s
Day & Night： IR cut filter
Angle Adjustment： Pan: -30° to 30°, tilt: 0° to 75°, rotate: 0° to 360°
Lens
Lens Type： Fixed focal lens, 2.8mm
Focal Length & FOV： 2.8 mm, horizontal FOV 106.4°, vertical FOV 58.4°, diagonal FOV 124.8°
Lens Mount： M12
Iris Type： Fixed
Aperture： F1.6
Illuminator
Supplement Light Type： IR
Supplement Light Range： Up to 30 m
Smart Supplement Light： Yes
IR Wavelength： 850 nm
Video
Main Stream： 50 Hz: 20 fps (3840 × 2160) 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 20 fps (3840 × 2160) 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub Stream： 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Third Stream： 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings.
Video Compression： Main stream: H.265/H.264/H.264+/H.265+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264
Video Bit Rate ：32 Kbps to 16 Mbps
H.264 Type： Baseline Profile/Main Profile/High Profile
H.265 Type： Main Profile
Bit Rate Control： CBR/VBR
Scalable Video Coding (SVC)： H.264 and H.265 encoding
Region of Interest (ROI) ：1 fixed region for main stream and sub-stream
Audio
Environment Noise Filtering： Yes
Audio Sampling Rate： 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Audio Compression： G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate： 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32-192 Kbps(MP2L2)/8 -320 Kbps (MP3)/16-64 Kbps (AAC-LC)
Network
Simultaneous Live View： Up to 6 channels
API Open Network Video Interface ：(Profile S, Profile G), ISAPI, SDK
Protocols： TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, WebSocket, WebSockets
User/Host： Up to 32 users. 3 user levels: administrator, operator and user
Security： Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Network Storage： NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Client： iVMS-4200, Hik-Connect, Hik-Central
Web Browser： Plug-in required live view: IE 10, IE 11 Plug-in free live view : Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+
Wide Dynamic Range (WDR)： 120 dB
SNR： ≥ 52 dB
Day/Night Switch： Day, Night, Auto, Schedule
Image Enhancement： BLC, HLC, 3D DNR
Image Parameters Switch： Yes
Image Settings： Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Interface
Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage： Built-in memory card slot, support microSD card, up to 512 GB
Built-in Microphone ：Yes
Audio： -IS:1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
Alarm： -IS:1 input, 1 output (max. 12 VDC, 20 mA)
Reset Key： Yes
Event
Basic Event： Motion detection (human and vehicle targets classfication), video tampering alarm, exception
Smart Event： Line crossing detection, intrusion detection, face detection
Linkage： Upload to FTP/memory card/NAS, notify surveillance center, trigger recording, trigger capture, send email
Deep Learning Function： Perimeter Protection Line crossing, intrusion Support alarm triggering by specified target types (human and vehicle)
General
Power： 12 VDC ± 25%, 0.54 A, max. 6.5 W, Ø 5.5 mm coaxial power plug, reverse polarity Protection PoE: (802.3af, Class 3, 36 V to 57 V), 0.22 A to 0.14 A, max. 8 W
Camera Material： Base: aluminum, cover: plastic
Camera Dimension： Ø 113.6 mm × 72.6 mm (Ø 4.5" × 2.9")
Package Dimension： 134 mm × 134 mm × 108 mm (5.3" × 5.3" × 4.3")
Camera Weight： Approx. 400 g (0.9 lb.)
With Package Weight： Approx. 635 g (1.4 lb.)
Storage Conditions： -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions： -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language： 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian General Function Anti-flicker, heartbeat, password reset via e-mail, pixel counter
