Drives
Speed Ratio:
1Stage (L1): 3:1 / 4:1 / 5:1 / 7:1 / 10:1
2Stage (L2): 15:1 / 20:1 / 25:1 / 30:1 / 35:1 / 40:1 / 50:1 / 70:1 / 100:1
Maximum torque: 1.5* Rated torque
Emergency braking torque: 2.5* Rated torque
Backlash Precision: L1 7 Arcmin , L2 12 Arcmin
Torsion rigidity: 1.8Nm/arcmin
Noise: less than 58dB
Input Shaft : 6.35mm,8mm,11mm,12.7MM,14mm,16mm,19mm
Output Shaft : 14mm
Max input speed : 8000rpm
Rated input speed : 4000rpm
