Camera
Image Sensor:1/2.7" Progressive Scan CMOS
Max. Resolution:2560 × 1440
Min. Illumination:Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001Lux @(F1.6, AGC ON), 0 Lux with IR
Lens
Focal Length:2.8 mm
FOV:2.8 mm, horizontal FOV 94°, vertical FOV 49°, diagonal FOV 114° Aperture:F1.6
Illuminator
Supplement Light Type:IR, White Light
Supplement Light Range:IR distance: up to 25 m,White light distance: up to 25 m
IR Wavelength:850 nm
PTZ
Movement Range (Pan):0° to 345°
Movement Range (Tilt):0° to 80°
Pan Speed:Up to 25°/s
Tilt Speed:Up to 20°/s
Power-Off Memory:Yes
Video
Main Stream:50 Hz: 20 fps (2560 × 1440, 1920 × 1080, 1280 × 720);60 Hz: 20 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-Stream:50 Hz: 20 fps (768 x 432).60 Hz: 20 fps (768 x 432)
Video Compression:H.265, H.264, MJPEG
Video Bit Rate:32 Kbps to 8 Mbps
H.264 Type:Baseline Profile/Main Profile/High Profile
H.265 Type:Main Profile
Audio
Audio Compression:G.711ulaw/AAC-LC
Audio Bit Rate:AAC-LC: 16 Kbps, 32 Kbps, 64 Kbps;G.711ulaw: 64 Kbps
Audio Sampling Rate:8 kHz/16 kHz
Environment Noise Filtering:Yes
Wi-Fi
Wi-Fi Protocols:IEEE802.11b, IEEE802.11g, IEEE802.11n, IEEE802.11ax
Frequency Range:2.4 GHz to 2.4835 GHz
Channel Bandwidth:20/40 MHz
Network
Protocols:IPv4/IPv6, HTTP, QoS, SMTP, NTP, RTSP, RTP, RTCP, TCP/IP, UDP, DHCP, Bonjour, SNMP, DNS, DDNS
API:ON/VIF (Profile S, Profile G, Profile T), ISAPI, SDK
User/Host:Up to 32 users;3 user levels: administrator, operator, and user
Security:Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
Client:Wired network: Hik-Connect, iVMS-4200;Wi-Fi: iVMS-4200(Wi-Fi connection with Hik-Connect directly is not possible)
Image Settings:Saturation, brightness, contrast, and sharpness adjustable by client software or web browser
Wide Dynamic Range (WDR):Digital WDR
Image Enhancement:BLC, HLC, 3D DNR
Privacy Mask:4 programmable rectangle privacy masks
Interface
Ethernet Interface:1 RJ45 10M/100M self-adaptive Ethernet port
Built-In Microphone:1 built-in microphone
On-Board Storage:Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Built-In Speaker:1 built-in speaker
Event
Basic Event:Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Linkage:Notify surveillance center, send email, trigger recording, trigger capture, audible warning
General
Power:12 VDC ± 25%, reverse polarity protection, 0.75 A, max. 9 W, Ø5.5 mm coaxial power plug,*A switching adapter is included in the package.
Dimension:5.19" × 6.45" × 12,31"
Weight:1.32 lb.
Material:Plastic
Operating Condition:-30 °C to 40 °C (-22 °F to 104 °F). Humidity 95% or less (non-condensing)
General Function:Heartbeat,anti-banding,mirror,password protection,password reset via email
Language:English, Ukrainian
Protection:IP66 (IEC 60529-2013)
