Special Features

Applicable scenarios: Designed specifically for FPV drones, supports 5-inch 225mm, 6-inch 260mm, and 7-inch 295mm wheelbases, with wide adaptability.
Structural design: 5mm arm thickness design ensures the stability of the frame during flight, suitable for racing and flight needs.
Material characteristics: Made of sturdy material, impact-resistant, weight, improves flight performance and controllability.
Easy installation: Modular design, simple assembly process, suitable for quick replacement and adjustment needs.
Wide compatibility: Suitable for a variety of FPV racing drone models including 230mm, to meet the needs of different flight enthusiasts.

Description

Name: 5inch
Propeller: 5 inches
Weight: 102g
Motor: 225MM
Dimensions: 145*172MM
Arm plate: 5MM
Top plate: 2.5MM
Bottom plate: 2.5MM
Side plate: 2.5MM
installation size: 19.3mm
Recommended configuration:
Flight controller: RF/Kiss/F3/F4/F7
Motor: 2205/2206/2207/2305/2306
ESC: 30A-50A
Propeller: 5 inches
4S 1500mAh-6s 11 50mAh
Name: 6inch
Propeller: 6 inches
Weight: 111g
Motor: 260MM
Size: 162*203MM
Arm plate: 5MM
Top plate: 2.5MM
Bottom plate: 2.5MM
Side plate: 2.5MM
bracket size: 19.3mm
Recommended configuration:
Flight control: RF/Kiss/F3/F4/F7
Motor: 2207 /2207.5/2305/2306/2407
ESC: 35A-60A
Propeller: 6 inches
4S 1500mAh-6s 1300mAh
Quantity: 1
Wheelbase: bottom plate
Technical parameters: value 2
Applicable vehicle type: fixed-wing aircraft
