Camera
Image Sensor: 1/1.8" Progressive Scan CMOS
Max. Resolution: 3840 × 2160
Min. Illumination: Color: 0.0005 Lux @ (F1.0, AGC ON),0 Lux with light

Lens
Lens Type: Fixed focal lens, 2.8mm
FOV: horizontal FOV 108.8°, vertical FOV 56.4°, diagonal FOV 134.3°
Aperture: F1.0
Illuminator
Supplement Light Type: White Light,IR
Supplement Light Range: Up to 30 m

Video
Main Stream: 50 Hz: 25 fps (Max 3840 × 2160); 60 Hz: 30 fps (Max 3840 × 2160)
Video Compression: Main stream: H.265/H.264/H.264+/H.265+

Image Enhancement: BLC,HLC,3D DNR,Distortion Correction,Defog
SNR ≥ 52 dB
Wide Dynamic Range: 130 dB (Scene-adaptive WDR)
Image Stabilization: EIS

Interface
Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage: Built-in memory card slot, up to 512GB
Built-in Speaker: Max. power consumption: 2W
Built-in Microphone: Arrayed dual-microphone
Alarm: 1 input, 1 output

Event
Basic Event: Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Linkage: Upload to FTP/NAS/memory card,notify surveillance center,trigger recording,trigger capture,send email
Smart Event: Scene change detection
Deep Learning Function
Face Capture: Yes
Perimeter Protection: Line crossing, intrusion, region entrance, region exiting(Support alarm triggering by specified target types (human and vehicle))

General
Power: 12 VDC ± 25%, 0.7 A, max. 8.5 W,Ø5.5 mm coaxial power plug,reverse polarity protection, PoE: IEEE 802.3af, Class 3, max.11W
Material: metal
Dimension: Ø138.3 mm × 115.4 mm(Ø5.4" × 4.5")
Weight: 750g (1.7lb)
Flashing Light: Red & Blue Light
Protection: IP67
Anti-Corrosion Protection: NEMA 4X
