Magnification: 1000
Observation method: transmission
Optical system Finite distance optical system
Eyepiece Wide field eyepiece WF10X/18MM
Objective lens Achromatic objective lens 4X, 10X, 40X, 100X
Eyepiece tube Hinged trinocular observation tube, tilted at 30°,
Interpupillary distance adjustment range: 48mm-75mm
(Trinocular optional, 100% bright photography)
Transducer Four holes for internal positioning of inward ball
Stage Double-layer mechanical mobile platform, size: 32mm×142mm,
Moving range: 75mm×40mm, with slice clamp
Focusing mechanism Coaxial coarse and fine focusing mechanism, fine adjustment scale value 0.002mm,
Coarse travel 37.7mm per circle, micro travel 0.2mm per circle, focusing range 20mm
Condenser Abbe condenser NA 1.25 with iris diaphragm
Light source 3W LED light, adjustable brightness
Camera interface (optional) 1X standard C interface
