Specification
Phase: 2 ;
step angle: 1.8degree
Step angle accuracey: ±0.09º
Rated current per phase: 5.0A
Resistance per phase: 0.45±10%;
Inductance per phase: 2.0MH±20%;
Holding Tq: 3N.m;
Rotor Inertia: 690gcm²;
Dielectric strength:500VAC;
Insulation resistance: 100M/min;
Insulation classe (UL): B;
Temperature Rise Max. 80K
Working ambient temperature: 0~50;
Working ambient humidity: 20%~90%RH;
Storage ambient temperature: -20~70;
Storage ambient humidity: 15%~90%RH;
