Speed regulation mode: change the spindle speed through the three-phase output inverter and adjust the frequency of the inverter.
Cooling method: air cooling
Power interface: optional 5-pin waterproof air connector. The air connectors are marked with "1", "2", "3", "4", "5", and "GND". "1", "2", and "3" are respectively connected to the inverter (U, V, W), and "GND" is connected to the inverter ground.
(Attention! the spindle "4" is connected to GND to ensure safety!!)
Grease lubrication
The working environment temperature of the spindle is usually -10~40.
Before installing the first electric spindle to rotate the spindle head by hand, you should feel flexibility and no blockage.
P4 fully sealed angular joint bearings can extend the life of the spindle.
The longer the length, the greater the torque and the greater the power.
Careful assembly makes the spindle more precise.
The accuracy is 0.01mm, and the coaxial cable is less than 0.0025mm
1. Our main shaft uses 4 bearings.
2. Bearings are resistant to high temperature and low heat
3. The ball bearing has low friction, low noise and long service life.
