Power Inverters
Features & Details
Powerful Function This variable frequency drive has a 1 or 3 phase input and 3 phase output.
Control mode: V/F control and vector control. Frequency setting mode: digital setting, analog
setting, serial communication setting, and so on. Various control techniques by both synchronization
and non-synchronization dynamically realize fast starting without changing brakes.
Low-Noise Operation: The variable frequency drive inverter features low noise and low
electromagnetic interference through the optimization of PWM control technology and electromagnetic
Sizes:
Sizes:
For 0.75/1.5/2.2KW:(for 380V)
Specifications:
Rated power: 0.75kw/1.5kw/2.2kw (for 380V type)
Rated output current:2.5A (for 0.75kw) 3.7A(for 1.5kw) 5A(for 2.2kw)
Input voltage: 3 phase 380V
Output voltage: 3 phase 380V
External dimension: 125X185X163 mm
Net Weight:2.5 kg
==========
Hign-concerned Chemical : none
is_customized : Yes
Output Current : 2.5A/3.7A/5.1A
Output Frequency : 0~600HZ
Model Number : LVF7000L
Output Power : 0.75/1.5/2.2KW
Type : DC/AC Inverters
Weight : 2.0KG
Size : 125*185*163
Output Type : triple
Rated Voltage : 380V 3PH-3PH
Color : Black
