Details
Clear Threads: The clear thread pitch is 0.05 inches, making it less likely to come off.
Ergonomic Handle: It is comfortable to hold and easy for you to work.

Application
This bridgeport drawbar is suitable for most milling machines with R8 collets and widely serves in the industries of hardware accessories, mechanical parts, mold manufacturing, and automation equipment.

Specifications
Style: Modern
Color: Black
Material: Steel
Surface Treatment: Hot Treatment
Assembly Required: No
Inch Tooth Diameter: 7/16
Thread Pitch: 1.25mm/ 0.05 in
Hexagonal Head Size: 19mm/ 0.75 in
Overall Length: 60cm/ 23.6 in
Effective Length: 47cm/ 18.5 in
Spacer Ring Width: 0.8cm/ 0.31 in
Thread Length: 3.9cm/ 1.53 in
Gross Weight: 0.75kg/ 1.65 lbs
Net Weight: 0.7kg/ 1.54 lbs
Package Size: 4x61x4 cm/ 1.57x24.02x1.57 in

Package Included
1x Milling Machine Draw Bar

Notes
1. Please note that if you want to obtain the "second life" after the end wears out, simply cut off at the "V" notch and remove the spacer.
2. Please note that this product does not include other accessories, this product needs to be used with R8 collets (not included).
3. Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before you order.
