120A V5 80A V5 60A V5 40A V5 p/n 30201400 30214201 30214101 30214002 Cont./Peak Current 120A/150A 80A/100A 60A/80A 40A/60A Input 3-6S LiPo 3-6S LiPo 3-6S LiPo 3-6S LiPo BEC Switch Mode: 5.2V/6V/7.4V, 8A/20A Switch Mode: 5.2V/6V/7.4V, 8A/20A Switch Mode: 5.2V/6V/7.4V, 8A/20A Switch Mode: 5.2V/6V/7.4V, 8A/20A Input /output wire 12AWG-150mm 12AWG-150mm 14AWG-150mm 14AWG-100mm/ 16AWB -75mm Input connector NO NO NO NO Output connector 4.0 Gold Connectors (Female) 4.0 Gold Connectors (Female) 4.0 Gold Connectors (Female) 3.5 Gold Connectors (Female) Size (mm) 77.2x34.6x19.2 69.8x34.6x19.2 68.8x34.6x18 47x28x14 weight (g) 93 92 73.5 44 ESC programmable through Transmitter and LED program card (purchase separately) DEO Technology / Active Freewheeling The DEO technology (Driving Efficiency Optimization) implemented in the ESC has multiple advantages: Rapider and smoother throttle response, better stability and flexibility during flight. Higher driving efficiency, longer flight time. Lower ESC temperature, more reliable operation. Soft Start-ups & Reverse Brake High-power BEC: High-power switch-mode BEC with continuous/peak current of 8A/20A and voltage adjustable among 5.2V, 6.0V & 7.4V allows users to have more electronic devices or devices with higher power like servo, flight controller, and on-board light on their aircraft. Multiple Protections: Multiple protection features include start-up, over-current, ESC thermal, capacitor thermal, overload, throttle signal loss (or Fail Safe), and abnormal input voltage effectively prolongs the service life of the ESC.
