Camera
Image Sensor: 1/2.8" Progressive Scan CMOS
Max. Resolution: 2560 × 1440
Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR
Zoom: 25 × optical, 16 × digital
Slow Shutter: Yes

Lens
Focal Length: 4.8 to 120 mm
FOV: Horizontal FOV 53.3° to 2.6°, vertical FOV 30.6° to 1.5°, diagonal FOV 60.5° to 3°
Focus: Auto, semi-auto, manual
Aperture: Max. F1.6
Zoom Speed: Approx. 3.4 s

PTZ
Movement Range (Pan): 0° to 360°
Movement Range (Tilt): -5° to 90°
Pan Speed: Pan speed: configurable from 0.1° to 300°/s; preset speed: 350°/s
Tilt Speed: Tilt speed: configurable from 0.1° to 160°/s, preset speed 200°/s
Proportional Zoom: Yes
Presets: 300
Preset Freezing: Yes
Patrol Scan: 8 patrols, up to 32 presets for each patrol
Pattern Scan: 4 pattern scans, record time over 10 minutes for each scan
Park Action: Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan
3D Positioning: Yes
PTZ Status Display: Yes
Scheduled Task: preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust
Power-Off Memory: Yes

Smart Features
Smart Event: line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection
Smart Tracking: Manual tracking, auto-tracking

Deep Learning Function
Face Capture: Detects up to 5 faces simultaneously, Supports detecting, tracking, capturing, grading, selecting of face in motion, and outputs the best face picture

General
Power: 12 VDC, Max. 24 W; PoE (802.3at)
Dimension: Ø 169 mm × 161 mm (Ø 6.65" × 6.34")
Weight: Approx. 2.45 kg (5.40 lb.)
