Feature:

The product is made of electronic components.
Built-in multi types of security functions, to use.
Low power consumption, theoretically rated power consumption is less than or equal to 1W.
Product channels are configured as one in, one out.
Products are widely used in industrial equipment, such as large motors, medical equipment, etc.
Multi-channel input and output, ultra-thin, intelligent, isolated safety grids.
Specification:
Product Name: current isolation transmitter
Model: GLG
Channel configuration: 1 in and 1 out, 1 in 2 out
Type: (Optional)
#1, 1 in 1 out, 4-20mA to 0-5V
#2, 1 in 1 out, 4-20mA to 0-10V
#3, 1 in 1`out. 4-20mA to 4-20mA
#4, 1 in 2 out, 4-20mA to 4-20mA
Power supply voltage: 24V ±10%
Rated power consumption: ?1W
Response time: ?100MS
Insulation strength: 2000V AC/1MIN
Input impedance: ?50?
Ambient temperature: -20 - 55 (°C)
Dimen sions: 100*22.5*114.5)mm)
Package list:
1 * Isolator
Note:
The actual product color may deviate from the photo due to light.
There may be a slight deviation in the measurement of product.
