بي ار في اوديو لوحة كروس اوفر ثنائية الاتجاه 4400 هرتز 2DF4400

KWD 17
ماركة
PRV AUDIO
وزن
301 g
– 1 +

مميزات خاصة

  • WOOFER IMPEDANCE SELECTION: This setting allows the same crossover to be used with 8 or 4 Ohms speakers and combinations of them (series or parallel connection) providing you with one solution for multiple cabinet variations
  • WOOFER ROLL-OFF CROSSOVER ADJUSTMENT: Some woofers respond excessively at the cut off frequency than others and need 12 dB/octave filters, where other woofers have a natural roll-off at or near the crossover point, and work well with 6 dB/octave filters. We give you the ability to select this on two of our crossovers: the 2DF1800 two-way crossover and the 3DF400/1800 three-way crossover
  • SPEAKER ATTENUATION: Match the output level of the different speakers in your cabinet with the setting; it helps in creating a seamless transition from high to mid to low-especially useful for when driver sensitivities do not match
  • BRIGHTNESS ADJUSTMENT:Many large format compression drivers naturally roll-off above 10 kHz. Our brightness adjustment offsets this phenomenon , applying attenuation below 6 kHz and increasing the energy at high frequencies for more brightness and definition

وصف

TWO-WAY CROSSOVER
Type: Two-Way
Impedance (Ohms): 8
Crossover Point (Hz): 4,400
Woofer Impedance (Ohms): 4/8
RMS Power (Watts): 290
Program Power (Watts): 580
Selectable Crossover Point (Hz): -
HF Attenuation (dB): -
Brightness: -
Woofer Octave Sel (dB octave): -
Midrange Attenuation (dB): -
Octave (dB): 12
