Drawn Cup Needle Roller Bearings, 10pcs HK0509 Open End Caged Bearing, 5mm Bore, 9mm OD, 9mm Width ST14 Steel Single Row Roller

KWD 3
Brand
HIPICCO
Weight
31 g
– 1 +

Special Features

  • [Model] - HK0509 (Bore Dia. (Fw)= 5mm, Outer Dia. (D)a= 9mm, Width (C)= 9mm)
  • [MATERIAL] - ST14 Steel Drawn Cup, ST13 Steel Cage, GCr15 Needle Roller, high load carrying capacity and stiffness, good heat tolerance.
  • [FEATURES] - The size is standardized, easy to install and disassemble, and easy to maintain; Pre-Lubricated. Good running properties; Low cross section, enable downsizing and suit for use in restricted mounting spaces.
  • [CAPABILITY] - Dynamic Load Rating (Cr): 2200N; Static Load Rating (Cor): 1790N; Limiting Speed (Oil): 36000rpm
  • [APPLICATION] - Needle bearings are used in automobile components such as rocker arm pivots, pumps, compressors, and transmissions, also used for office equipment, paper-towel dispensers, exercise equipment, appliances and two-speed gearboxes.

Description

Specification:
Model: HK0509
Drawn Cup Material: ST14 Steel
Cage Material: ST13 Steel
Needle Roller Material: Chromium Steel (GCr15)
Bore Diameter (Fw): 5mm
Outside Diameter (D): 9mm
Width: 9mm
Static Load Capacity (Cor): 1790N
Dynamic Load Capacity (Cr): 2200N
Maximum Rotational Speed (Oil): 36000rpm
Number of Packs: 10 Pcs
Description:
Drawn Cup Needle Roller Bearing features a deep drawn, thin-walled outer ring. They are compact bearings with high load carrying capacity and stiffness.
These bearings are especially suitable for high dynamic loads or radial-limited installation. They are mounted with a tight interference fit in the housing.
Shoulders or snap rings are not required to locate the bearing axially, thus enables a simple and economic design of the housing bore.
For various applications such as planetary gears in automobiles, constant mesh gearboxes, agricultural and construction equipment, pumps and compressors, and two-cycle engines, among others.
NOTE:
Install with a press machine or special tools instead of hammers because beating may lead to local deformation or brittle fracture.
