Features:- Resolution: 16 Bits- Programmable Sample Rate: 8 to 860 Samples/Second- Power Supply/Logic Levels: 2.0V to 5.5V- Low Current Consumption: Continuous Mode: Only 150µA Single-Shot Mode: Auto Shut-Down- Internal Low-Drift Voltage Reference- Internal Oscillator- Internal PGA: up to x16- I2C Interface: 4-Pin-Selectable Addresses- Four Single-Ended or 2 Differential Inputs- Programmable ComparatorDescription:The ADS1115 are precision analog-to-digital converters (ADCs)with 16 bits of resolution offered in an ultra-small, leadless QFN-10 package or an MSOP-10 package. The ADS1115 are designed with precision,power,and ease of implementation in mind.The ADS1115 feature an onboard reference and oscillator.Data are transferred via an I2C-compatible serial interface;four 20 slave addressescan be selected. The ADS1115 operate from as single power supply ranging from 2.0V to 5.5V. The ADS1115 can perform conversions at rates up to 860 samples per second (SPS).An onboard PGA is available on the ADS1115 that offers input ranges from the supply to as low as +256mV,allowing both large and small signals to be measured with high resolution.The ADS1115 also features an input multiplexer(MUX)that provides two differential or four single-ended inputs. The ADS1115 operate either in continuous conversion mode or a single-shot mode that automatically powers down after a conversionand greatly reduces current consumption during idle periods.The ADS1115 are specified from -40C to +125 CApplication:- Portable Instrumentation- Consumer Goods- Battery Monitoring- Temperature Monitoring- Factory Automation and Process ControlsPackage included:5pcs ADS1115 16 Bit 16 Byte 4 Channel I2C IIC Analog-to-Digital ADC PGA Converter for Arduino Raspberry Pi DIY and Other Experiments
