مميزات خاصة

✅ ALL-METAL GEARS: High-temperature resistance, high abrasion resistance, strong load capacity, sturdy and durable, effectively protect the gear box motor body.
✅ PURE COPPER WIR: With precision winding technology to ensure that each coil of copper wire is tightly wound on the motor rotor, which increases the motor efficiency by 30%.
✅ DOUBLE SHAFT: The front shaft is output from the gear box, D shaped, low speed and large torque; The rear shaft is output from the motor body, round shaft, high speed and low torque, suitable for installing rotary position encoder.
✅ POSITIVE-NEGATIVE ROTATION: You also can adjust the speed, but the motor speed can only be reduced, can not be raised. Low noise and high torque, and multi voltage (DC 12V, 24V) and multi speed (10~1280RPM) are optional.
✅ RELIABLE GURANTEE: Any quality issues, we promise 100% unconditional return service. If you need other voltage and rpm, please feel free to contact us!

وصف

Specifications:
Rated Voltage: 12V
Rated Current: 1.5A
No-load Speed: 61RPM
Rated Speed: 46RPM
Rated Torque: 22kgf.cm (2160mN.m) (310oz.in)
Material: Metal
Reduction Ratio: 1:131
Gearbox Size: Φ37 x 26.5mm (Φ1.46 x 1.04in) (D*L)
Motor Total Size (include shaft): Φ37 x 118mm (Φ1.46 x 4.65in) (D*L)
Front Shaft Size: Φ6 x 21mm (Φ0.24 x 0.83in) (D*L)
Front Shaft D Shape Size: 5.5 x 12mm (0.22 x 0.47in) (D*L)
Rear Shaft Size: Φ3.175 x 13.5mm (Φ0.125 x 0.53in) (D*L)
Mounting Hole Size: 6-M3 (not included)
Weight: About 310g (10.9oz)

Application:
Home appliances, audio-visual products, office equipment, massage and health care, toys, electric tools, intelligent electromechanical systems, etc.

Packages:
-- 1 x DC Geared Motor

PLEASE NOTE:
1.Power supply: Please pay attention to the voltage and current range, otherwise the motor performance and motor life will decline.
2.Motor wiring: Red lead to the positive electrode, black lead to the negative pole, if reversed, the motor will rotation in the opposite direction.
3.Overload: As far as possible within the specified load range, prohibit motor blocking or close to the stall state for too long time to runs. Otherwise, the motor will burn out.
4.Motor use temperature: 0℃ - 70℃
5.Motor storage:
-- Storage temperature: 0℃ - 40℃;
-- Storage humidity: 15% -90% RH;
-- Avoid placing in high temperature, high humidity and corrosive gases.
6.Handling motors: Gently, as far as possible the use of motor shell part.
