Characteristic Parameter:

Delay distance: 10% below of the detection distance.
Detection object: Magnetic metal(the detection distance decreases when it is non-magnetic metal).
Consumption current: 13mA below.
Control output: 200mA below.
Loop protection: Reversal connection protection, Surge absorption, load short-circuit protection.
Ambient temperature & humidity: -30~+65 ℃; 35~95%RH.
Insulation impedance: 50Mohm above(DC500 megameter) between charging part and housing.
Withstand voltage: AC 1000V 50/60Hz 1 min between charging part and housing.
Temperature influence: temp range -30~65 ℃ at 23℃, ±15% detection distance. Temp range -25~60 ℃ at 23℃, ±10% detection distance.
Voltage influence: Inside ±15% rated supply voltage range, at rated supply voltage value, inside ±10% detection distance.
Protection structure: IP67.
Material: (Housing: Nickel plated brass), (Detection surface: ABS)
