Feature:
1. The dc motor with metal belt pulley, fine workmanship, sturdy and durable
2. The length of the brush motor is 100mm, diameter is 68mm, shaft length is 28mm, shaft diameter is 8mm, 2 fixed hole spacing of motor is 36mm, the sprocket is 25H type, 9 tooth sprocket
3. Made of high-quality aluminum, the synchronizing wheel motor with good performance, stable, long service time
4. This mini dc motor is a small DC brush motor
5. This small motor is suitable for electric scooters, electric bicycles

Specification:
Item Type: Brush Motor
Modelr: 6812
Material: Aluminum Alloy
Weight: 1132g
Voltage: 24V DC
Output Power: 100W
Box Length: 3-15/16 "(100mm)
Box Diameter: 2-11/16 "(68mm)
Drive Shaft Length: 1-1/8 "(28 Mm)
Drive Shaft Diameter: 5/16 "(8 Mm)
Installation Hole Distance:1-9/16 "(40mm)
No-Load Speed: 3500 Rpm/ Min
Loading Speed: 2400-2700 Rpm/ Min
Maximum Current: 8.9 A
Axial Diameter: 8mm/0.3inch (one Side Milling Groove: 1mm/0.04inch)

Package List:
1 x Motor
