Replaces Part Number: 379160, 1101425 Gear Box Linkage Assembly.
Automotive Replacement Power Steering Gear Boxes: RV Gear Box Linkage Compatible with Kwikee 22 23 24 26 28 30 31 32 33 36 37 38 39 42 and 47 Automatic Electric Gear Box Linkage Steps Replacement Kit.
Specification:
Color: Grey
Material: Steel
Size: 8-1/4" L x 3-1/4" H x 4-1/4" W
Replace Part Number: 379160, 1104425. Fit for 366043 1101428 379147 676061 2141001 Gearbox Motor Parts
Package Includes: 1* "A" Linkage Gearbox, 2* Washers, 1* Installation Instruction
Installation Instructions:
1.Before replacing, please disconnect the power supply of the steps.
2.Disconnect the power plug from the motor assembly.
3.Remove the 3 screws holding the motor assembly with a 10mm socket.
4. Lower the motor straight down being certain not to drop the gear, washers and pin on the gear assembly side of the motor.
5. Remove the 4 bolts on each corner of the gear assembly.
6. Remove the lock wire and pin from the arm connecting the step to the gear assembly.
7. Remove the gear assembly and replace it with a new one.
8. Reinstall the motor using the new gear (the small one) from the gear assembly.
9. Insert the three bolts securing the motor.
10. Reconnect main step power (four-way connector) while staying clear of moving parts.
11. Test the step and finished !
Friendly Reminder:
1.This item does not include the motor assembly, only gearbox linkage assembly.
2. Refer to the above steps to help you install, if you still have doubts, please feel free to consult us, we will provide you with the most professional support
Noted Please: 100% brand new, ready to install out of the box. Please confirm the vehicle's Information Before Placing Order, Avoid unnecessary expenses caused by wrong purchases, Wish you have a good shopping experience, Thank You!
