Product parameters:
Working temperature: -25℃~80℃
Product size: 55 * 55 * 16mm/2.17*2.17*0.63in(L*W*H)
Installation hole diameter: 3mm/0.12in
The power supply voltage is DC6.5V-27V, the power supply cannot be reversed or exceed 27V, otherwise, the module may be burned out. It is recommended to connect a 15A fuse in series at the power input terminal.
Dual motor interface, with each rated output current of 7A and peak current of 50A. The motor interface must not be short-circuited, and it is recommended to connect a 10A fuse in series
The enable signal and the forward and reverse control signal control the voltage at 3-6.5V
Enable signal terminal (ENA) input PWM for speed regulation, with a PWM frequency range of 0-10KHZ and a minimum PWM pulse width of 10us

Suitable motor parameters:
For motors with a rated voltage of 24V, it is appropriate to identify motors with a rated power of 115W or below, or motors with a rated current of 7A or below, which can operate at full capacity for extended periods.
For motors with a rated voltage of 12V, it is appropriate to identify motors with a rated power of 40W or below, or motors with a rated current of 7A or below, which can operate at full capacity for extended periods.
