5 دبوس

KWD 4
مقاس5 دبوس
– 1 +

مميزات خاصة

  • -Rated Voltage: 300V; Rated current: 8A; Use wire diameter: 16-28 AWG, Pin Distance: 3.5MM
  • -Pluggable Terminal Blocks: These connectors offer the flexibility of disconnecting or swapping out wires or components without unsoldering. They have a plug design, enabling easy installation and removal.
  • -Material: Use high-quality plastic PA66, fixed, better shockproof design, ensure long-term closed connection and safety and reliability.
  • -Wide Application: Terminal blocks are commonly used in various electronic devices and systems, including industrial equipment, consumer electronics, automotive applications, and more.
  • -Package Content: 10 PCS x 6 Pin 3.5mm Pitch Male Plug connector. If you need male and female connectors, please buy one set connector.This model is male connector.

وصف

Specification：
-3.5MM Male Plug Connector
-Material: Nylon + Copper
-Pin Header: Brass, Tin plated
-Shell: PA66, UL94V-0
-Terminal Pitch: 3.5mm
-Type: 2/3/4/5/6/8Pin
-Rated Value: 300V
-Rated Current：8A
-Wire Range: 26-18AWG(0.1mm²-0.5mm²)
-Temperature range: -104℉~221℉
-Stripping length: 5-6mm
-Maximum tightening torque: 0.1Nm(0.88lb-in)
