Stemedu 150KG DS51150 محرك توجيه رقمي مؤازر معدني 12 فولت مؤازر آلي عالي الجهد مقاوم للماء مع قرن مؤازر 25T (زاوية التحكم 270 درجة)

KWD 16
– 1 +

مميزات خاصة

  • Operating Voltage: 9 ~ 12.6 DC Volts
  • Speed: 0.24 sec/60°(10V) / 0.21 sec/60°(12V) / 0.19sec/60°(12.6V)
  • Torque: 150kg/cm at(10V),165kg/cm.at (12V),173kg/cm.at(12.6V)
  • Surface waterproof, extremely strong unique stainless steel gears, CNC aluminun shell
  • This 150kg large servo motor is designed for large scale RC cars, Robots, Industrial

وصف

Description:
Motor Type: DC Motor
Torque: 150kg/cm at(10V),165kg/cm.at (12V),173kg/cm.at(12.6V)
Speed : 0.24 sec/60°(10V) / 0.21 sec/60°(12V) / 0.19sec/60°(12.6V)
Weight: 165 g (2.12 oz)
Operating Voltage: 9 ~ 12.6 DC Volts
Gear Type: Copper & Aluminum
Middle Shell: CNC aluminium
Top and bottom material: Plastic

Control System: PWM(Pulse width modification)
Pulse width range: 500 ~ 2500usec
Neutral position: 1500usec
Running degree: 270° (when 2500μsec)
Dead band width: 3 usec
Operating frequency: 50-330Hz
Rotating direction: Counterclockwise (when 500 ~ 2500 μsec)

Size: 65 x 30 x 48mm
Weight: 175g

Package Includes:
1 x DS51150 Digital Metal Robotic Servo
1 x 18T Adjustable metal servo arm
1 x Screw accessories pack (like pictures)
