Package include :
3 x Power Relay ,3× Socket Base ,1 x Rail Slotted Aluminum , 2 x Screw

Relay Features

1.Slim size: width 5mm(0.2'')
2.Switching capacity: 6A
3.High breakdown voltage 4kV(between coil and contacts)
4.Surge voltage up to 6kV (between coil and contacts)
5.Meeting VDE0700/0631 reinforce insulation
6.High sensitive: Approx.170mW
7.Sockets available
8.Environmental friendly product (RoHS compliant)
9.Outline Dimensions: (28.0x5.0x1 5.0)mm

Relay Contact Data

1.Contact arrangement: 1H,1Z
2.Contact resistance: 100mQ(1A 6VDC)
3.Contact material: AgSnO2, AgNi
4.Contact rating (Res.load): 6A 250VAC/30VDC
5.Max. switching voltage: 400VAC/125VDC
6.Max. switching current: 6A
7.Max. switching power: 1 500VA/180W
8.Mechanical endurance: 1x 10次
9.Electrical endurance: H:6x 10° (AgNi, 6A 250VAC/30VDC85°C，1s9s )Z:3x10*(NO, AgNi, 6A 250VAC/30VDCElectrical endurance85°C，1s9s )1x10*(NO, AgNi, 6A 250VAC/30VDC .85°C，1s9s )

Relay Characteristics

1. Insulation resistance: 1000M 2( at 500VDC)
2. Dielectric Between coil & contacts: 4000VAC 1Min
Strength Between open contacts: 1000VAC 1 Min
3. Operate time(at nomi.volt.): ≤8ms max.
4. Release time(at nomi.volt.): ≤4ms max.
5. Shock Functional: 49m/s2
Resistance Destructive: 980m/s?
6. Vibration resistance: 10~ 55Hz 1mm
7. Humidity: 5%~85%RH
8. Ambient temperature: -40°C~+85C
9. Termination: PCB
10. Unit Weight: Approx. 5g
11. Construction: Plastic sealed, Flux proofed
